| Input |
1 instrument/line/speaker level |
| Input Connectors |
1/4" jack |
| Input Type |
Unbalanced, RF filtered |
| Insert Impedance |
150k Ohm typical |
| Max Input |
+20dBu (0dB pad); +40dBu (20dB pad); +60dBu (40dB pad) |
| Output |
(Thru) 1 parallel from input jack, 1/4" Unbalanced, RF filtered |
| Output Connectors |
XLR male balanced |
| Output Impedance |
150k Ohm typical |
| Max Output |
0dBu |
| Transformer |
Custom dbx mu-metal-shielded |
| Frequency Response |
20Hz to 20kHz, +/-2.5dB |
| Noise |
<-105dB unweighted, 22kHz BW |
| THD |
<0.01%, 20Hz to 20kHz BW; <0.005%, 1kHz |
| Dimensions |
5.82" L X 5.44" W X 2.20" H (148 x 138 x 56mm) |
| Unit Weight |
1.4 lbs / 0.65 kg |
