| Input Connectors |
1/4" TRS and XLR, Floating Balanced; XLR: Pin 2 hot Phone: Tip Hot |
| Input Impedance |
40k |
| Max Input |
+24dBu, Balanced or Unabalanced (Absolute) |
| CMRR |
>45dB (any Frequency) |
| Detector Input |
Connector: 14" TRS phone, Floating Balanced |
| Detector Input Impedance |
>200k |
| Detector Input Max Level |
+28dBu, Balanced or Unbalanced |
| Output Connectors |
1/4" TRS phone, Unbalanced; XLR, floating balanced; pin 2 hot |
| Output Impedance |
Balanced 200 ohm, unbalanced 100 ohm |
| Max Output |
(Balanced): +24dBm; <0.3% THD; (Unbalanced): +20dBm; <0.3% THD |
| Noise |
<-90dBu, Unweighted (20Hz - 20kHz) |
| Frequency Response |
20Hz -20kHz, +0, -0.5dB; +0, -3dB 0.5Hz and 90kHz. |
| THD |
<0.2%, Typical, any amount of compression up to 40dB @ 1kHz |
| Compressor Threshold Range |
-40dBu to +20dBu |
| Compressor Threshold Characteristic |
OverEasy® or hard knee |
| Compressor Ratio |
Variable 1:1 to :1 thru to -1:1; >60dB maximum compression |
| Compressor Attack Time |
Program dependent; typically 15ms for 10dB, 5ms for 20dB, 3ms for 30dB |
| Compressor Release Time |
Program Dependent; Typically 8ms for 1dB, 80ms for 10dB, 400ms for 50dB; 125dB/sec rate |
| Dynamic Range |
>113dB |
| Gain Adjustment Range |
Variable from -20dB to +20dB |
| Stereo Coupling |
True RMS Power summing |
| Summing |
1/4" TRS phone jack |
| Operating Voltage |
DO: 90-130VAC, 50/60Hz; EU: 200-250VAC, 50/60Hz |
| Power Connector |
IEC receptacle |
| Dimensions |
1.75" x 19" x 6.5" (4.45cm x 48.2cm x 16.51cm) |
| Unit Weight |
4.452 lbs (1.99 kg) |
| Shipping Weight |
6.62 lbs (2.99 kg) |
