Features
Removable dimming modules
DMX-512 and analog (0-10V) input
Each channel is able to configured as dimming or switching mode
Built-in MCB for each output
Thermo-controlled fan
Self-testing function to test without a console
Specifications
Power Input: AC 100-240V (3Ø4W)
Protocol: DMX-512, DC 0-10V
Installation: 19” 4U standard rack
Model Channels Output (per channel) Dimension (mm) Weight (kg)
DX-1210 12 10A 482(W)×176(H)×297(D) 18.5
DX-1220 12 20A 21
DX-1230 12 30A 21.5
