| Nominal Diameter |
380 mm (15 in) |
| Nominal Impedance |
8 ohm |
| Minimum Impedance |
6.4 ohm |
| Nominal Power Handling (AES) |
700 W |
| Continuous Power Handling |
1400 W |
| Sensitivity (1W/1m) |
97 dB |
| Frequency Range |
40 - 2000 Hz |
| Voice Coil Diameter |
100 mm (4 in) |
| Winding Material |
Copper |
| Former Material |
Glass Fibre |
| Magnet Material |
Ceramic Ring |
| Winding Depth |
21 mm (0.83 in) |
| Magnetic Gap Depth |
9 mm (0.35 in) |
| Flux Density |
1.15 T |
|
