| Nominal Diameter |
200 mm (8 in) |
| Nominal Impedance |
8 ohm |
| Minimum Impedance |
7.2 ohm |
| Nominal Power Handling (AES) |
200 W |
| Continuous Power Handling |
400 W |
| Sensitivity (1W/1m) |
98 dB |
| Frequency Range |
90 - 5000 Hz |
| Voice Coil Diameter |
50 mm (2 in) |
| Winding Material |
Copper |
| Former Material |
Kapton |
| Magnet Material |
Ceramic Ring |
| Winding Depth |
9.5 mm (0.37 in) |
| Magnetic Gap Depth |
8 mm (0.31 in) |
| Flux Density |
1.25 T |
|
