Teknik Özellikler
Frequency Response: 45 Hz ÷ 20 kHz
Max SPL @ 1m: 131dB
Horizontal Coverage Angle: 100'
Vertical Coverage Angle: 60'
Transducers
Compression Driver: 1", 1.75" v.c
Woofer: 15", 2.5" v.c
In/Out Section
Input Signal: bal/unbal
Input Connectors: XLR, Jack
Output Connectors: XLR
Input Sensitivity: -2 dBu/+4 dBu
Processor Section
Crossover Frequencies: 1800 Hz
Protections: Thermal, RMS
Limiter: Soft Limiter
Controls: Linear, Boost, Stage, Volume
Power Section
Total Power: 2100 W Peak
High Frequencies: 700 W Peak
Low Frequencies: 1400 W Peak
Cooling: Convection
Connections: VDE
Cabinet/Case Material: PP Composite
Hardware: 1 x M10 Top, 1 x M10 each side
Handles: 1 Top, 1 Each Side
Pole Mount/Cap: Yes
Grille: Steel
Colour: Black
Size
Height: 717 mm / 28.23”
Width: 415 mm / 16.34”
Depth: 410 mm / 16.14”
Weight: 22 kg / 48.5 lbs
