Mic Inputs: 12 (8x XLR / 4x Combo XLR)
Stereo Inputs: 2
Master Output: 2 (Left/Right balanced XLR)
Smart Outputs: 4 (assignable balanced XLR)
Speaker Outputs: 4x 4-pole speaker connectors
Internal busses: 16
Stage monitor: 1 TRS Jack output
Headphone: 1 TRS Jack output
Screen: 7″ high definition touch screen
Operation system: Android system
Remote system: IOS app for Ipad
Network: Yes, via WiFi module
Sample Frequency: 48 KHz
AD/DA: 192 KHz, 24-bit
DSP: 40 bit float point, SHARC processor
Effects: up to 8 assignable effect modules
Amplifier Power: 4x 150 watts (RMS)
AES/EBU: Output XLR
S/PDIF: Input / Output (RCA Phono)
USB Interface: 2 for playback/recording, scene/setting storage and system updates
Power Supply: 100-120V/ 200-240V ~ 50/60Hz IEC power supply
