Type
Condenser, externally polarized
Acoustical operating principle
Pressure gradient transducer
Transducer Ø
25.4 mm, 1 in
Polar pattern
Cardioid
Frequency range
20 ... 20,000 Hz
Sensitivity
9 mV/Pa, -41 dBV/Pa
Equivalent noise level
14 dB (A)
Max. SPL for 0.5 % THD
152 dBSPL, 0 dB pre-attenuation
Signal / noise ratio
79 dB (A)
Dynamic range
138 dB (A)
Pre-attenuation pad
0 dB
-10 dB
Low-cut filter
linear
80 Hz (6 dB/oct)
Internal impedance
150 Ω
Rated load impedance
1,000 Ω
Supply voltage
48 V ± 4 V
Current consumption
5.5 mA
Connector
Gold plated 3-pin XLR
Microphone dimensions
51 dia. x 183 mm , 2 dia. x 7.2 in
Microphone net weight
