Speaker: 12″ custom design high output
HF Unit: High frequency tweeter
Finish: Black carpet covering, corner protectors, feet, scoop handle
Power Output: 120W @ 8ohms RMS
@ 1% THD: 150W @ 4ohm (with PX12) RMS
Distortion (amp): 0.008% (50W @ 8ohms)
Maximum SPL: 116dB
Mic Input Impedance: 6k ohms balanced
Line Input Impedance: 33k ohm balanced
Mic Input Sensitivity: -30dBu
Line Input Sensitivity: -10dBu
Equalisation: Hi 12dB@5kHz Q=2, Mid 15dB@1.5kHz Q=0.9, Lo 12dB@90Hz Q=3.6
Notch Filter: -12dB @ 300Hz to 6kHz, Q=3.3, switchable with LED
Input Connection: Balanced XLR and Jack
Output Connection: Jack link out socket
Power Requirements: 230V Range 10% ~ 50/60Hz 4A Max
Voltage Selector: 115V Range 10% ~ 50/60Hz 8A Max
Dimension W*H*D: 553 x 380 x 450 (mm)
Weight (net/shipping): 16kg / 19kg
