TP X10A |
| System Type |
2-Way Active Vented Speaker |
| Transducer Low |
10" Woofer, 1.5" voice coil |
| Transducer Driver |
1" Ferrite Tweeter, 1" Voice Coil |
| Horn Coverage H° x V° |
90°H x 60°V |
| Frequency Response (-6dB) |
65Hz-20KHz |
| Crossover Frequency |
1900 Hz |
| Max SPL |
116dB at 1M |
| Power Rating |
240W (PROGRAM) / 480W (PEAK) |
| Connector |
Line In & Link With XLR |
| External Controls |
Volume Control/ Power ON with Green LED / Clip Limiter with Red LED |
| Electronic Protections |
Thermal / Overload / Analog limiter / Compressor |
| Power Supply |
110V-240V ~50/60Hz |
| Enclosure Construction |
Plastic cabinet, Trapezoidal & Monitor shape, Metal grille, Rubber foot, 1 x Handle-On Top |
| Mounting |
36mm standard pole-mount |
| Dimensions (HxWxD) |
460 x 285 x 265mm |
| Net Weight |
6.92 (kg) / 15.26lbs |
